Komfortní jednotka 3C0937049AH - Centrální řídicí jednotka komfortní elektroniky VW Passat B6 FL/B7

VCDS IDENTIFIKACE AR:

Address 09: Central Elect.
Part No SW: 1K0 959 433 AR    HW: 1K0 959 433 AR
Component: BCM PQ35 H+      103 0221
Revision: 00103011   Serial number: 00000312080001
Coding: 6D180A3E907F0041680080000040100054885C0C6D604C0820200040
Shop #: WSC 00028 000 00000
VCID: 3479BFAE1D2F6D7EBB-8021

Component Protection: Active
Subsystem 1 - Part No SW: 1K1 955 119 F    HW: 1K1 955 119 F
Component: Wischer 20080 21  0512
Coding: 009795

Platform: PQ35
Protocol: UDS

LONG CODING PRO AR VERZI:

Formát: XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX
(19 bajtů v HEX pro AR verzi)

Byte 00: Země/Region
07 = Evropa RoW
2D = Německo
35 = UK (RHD)

Byte 01: Systémová konfigurace
Bit 0-3 = Typ vozidla
Bit 4-7 = Varianta karoserie

Byte 02-03: Výbava základní
El. okna, zrcátka, centrál, alarm

Byte 04-05: Komfort funkce
KESSY, Safe, Selective, Auto-lock

Byte 06-07: Světla
Xenon, AFS, LED, Corner, Auto

Byte 08-09: Asistenti
PDC, OPS, Park Assist, Camera

Byte 10-11: Klimatizace
Climatronic, Stand heating, Rest

Byte 12-13: Infotainment
RNS, Bluetooth, USB, Voice

Byte 14-15: Speciální
Tow bar, Solar roof, Heated seats

Byte 16-17: Kalibrace
Specific adjustments

Byte 18: Checksum

Příklad AR pro Golf GTI Edition 30:
6D 18 0A 3E 90 7F 00 41 68 00 80 00 00 40 10 00 54 88 5C

ADAPTACE SPECIÁLNÍ PRO AR:

=== KESSY AR ===
IDE00021-ENG116716-Access control 2-Learned keys
Value: 1-8 (počet klíčů)

IDE00167-MAS00395-Access control-Comfort opening
Value: active/not active

IDE00168-MAS00396-Access control-Comfort closing
Value: active/not active

IDE00169-MAS00397-Access control-Automatic locking
Value: active/not active

IDE00170-MAS00398-Access control-Approach lighting
Value: 0-60 seconds

=== BI-XENON AR ===
IDE00094-ENG116994-Xenon headlights installed
Value: installed/not installed

IDE00095-ENG116995-Adaptive front lighting
Value: active/not active

IDE00096-ENG116996-Cornering light
Value: active/not active

IDE00097-ENG116997-Highway light
Value: active/not active

=== PARK ASSIST AR ===
IDE00198-MAS00542-Park Assist installed
Value: installed/not installed

IDE00199-MAS00543-Park Assist button
Value: active/not active

IDE00200-MAS00544-Display type
Value: optical/acoustic/both

=== ENERGY AR ===
IDE00287-MAS00621-Battery monitoring
Value: AGM/Lead acid/EFB

IDE00288-MAS00622-Second battery
Value: installed/not installed

IDE00289-MAS00623-Quiescent current reduction
Value: normal/maximum

=== SPECIAL AR ===
IDE00374-MAS00751-Software version
Read only - shows AR specific

IDE00375-MAS00752-Hardware version
Read only - confirms AR

IDE00376-MAS00753-Production date
Read only - 2007-2009

B10F5 09 - Function Restriction due to Undervoltage
B10F6 09 - Function Restriction due to Overvoltage
B116D 29 - Left Low Beam Output - Short to Ground
B116E 29 - Right Low Beam Output - Short to Ground
B1192 29 - Left Cornering Light - Circuit Malfunction
B1193 29 - Right Cornering Light - Circuit Malfunction
B200A 16 - Control Module Coding Not Valid
B200B 16 - Control Module, Hardware Incompatible
01542 - Comfort CAN - Malfunction - Intermittent
01599 - KESSY; Key 1 - Low Battery
02635 - Steering Column Lock - No Communication
16955 - Key 1 - Adaptation Limit Exceeded
18058 - CAN Gateway - No Communication
18265 - Load Management - Second Battery Low

KOMPLETNÍ SETUP AR:

1. Identifikace:
   [09 - Central Elect.]
   Ověřit AR verzi

2. Backup:
   Long coding - uložit!
   Adaptation list - export

3. Component Protection:
   [Security Access - 20103]
   Online SVM code needed

4. Long Coding AR:
   [07 - Long Coding]
   19 bajtů pro AR
   Helper - použít

5. Adaptace AR:
   [10 - Adaptation]
   IDE kanály pro AR

6. Basic Settings:
   [04 - Basic Settings]
   Všechny skupiny

7. Test:
   [08 - Read Measuring Blocks]
   Kontrola všech funkcí

KESSY AR SETUP:

Specifické pro AR verzi:

1. Hardware check:
   - 3x anténa (dveře + kufr)
   - Frekvence 433.92 MHz
   - Start/Stop button

2. Long Coding:
   Byte 04, Bit 6 = 1 (KESSY)
   Byte 05, Bit 0-3 podle výbavy

3. Adaptace AR:
   IDE00021 = počet klíčů
   IDE00167 = active (comfort open)
   IDE00168 = active (comfort close)
   IDE00169 = active (auto lock)
   IDE00170 = 10 (approach light)

4. Kalibrace antén:
   [04 - Basic Settings]
   Group 003 - KESSY calibration

5. Test dosahu:
   Měřit 2.5-3m
   Všechny směry

BI-XENON AFS PRO AR:

Nativní podpora v AR:

1. Long Coding:
   Byte 06-07 nastavit pro xenon

2. Adaptace:
   IDE00094 = installed
   IDE00095 = active (AFS)
   IDE00096 = active (corner)
   IDE00097 = active (highway)

3. Kalibrace:
   [55 - Headlight Range]
   [04 - Basic Settings]

   Vozidlo:
   - Vodorovně
   - Nádrž 50%
   - Řidič ve vozidle

4. Test AFS:
   - Motor běží
   - Volant vlevo/vpravo
   - Světla následují

5. Tourist mode:
   IDE00098 = RHD/LHD

SOFTWARE UPDATE AR→AR2:

Doporučený update:

1. Důvody:
   - KESSY fix
   - Battery drain fix
   - AFS improvement
   - Stability

2. Požadavky:
   - ODIS Service 5.0+
   - Online přístup
   - Baterie nabíječ

3. Postup:
   [09 - Central Elect.]
   [30 - Software Update]

   Online flash:
   - 15-20 minut
   - Neodpojovat!

4. Po update:
   - Long coding restore
   - Adaptace znovu
   - Test všech funkcí

5. Verze AR2:
   SW: 0221 → 0223

BATTERY DRAIN FIX AR:

Specifický problém AR:

1. Diagnostika:
   MVB 120 - Quiescent current
   Měřit po 20 min
   Max 30mA (AR 25mA)

2. Software fix:
   Update na AR2
   Nebo patch 0221→0222

3. Adaptace:
   IDE00289 = maximum
   (Quiescent reduction)

4. Hardware check:
   - Comfort modul
   - Gateway
   - Všechny door moduly

5. Měření:
   Před: 40-50mA
   Po: 20-25mA

MVB 120 - Power Management AR:
1: Battery voltage (11.0-14.8V)
2: Quiescent current (0-50mA)
3: Generator load (0-100%)
4: Battery state (0-100%)

MVB 125 - KESSY AR:
1: Key 1 battery (0-100%)
2: Key 2 battery (0-100%)
3: Response time (0-1000ms)
4: Signal strength (-100-0 dBm)

MVB 130 - AFS Status AR:
1: Left swivel angle (-15°-+15°)
2: Right swivel angle (-15°-+15°)
3: Leveling front (0-100%)
4: Leveling rear (0-100%)

MVB 135 - Software AR:
1: SW version (0221/0223)
2: HW version (AR)
3: Coding version
4: Dataset version

MVB 140 - LIN-Bus AR:
1: LIN 1 status (OK/Error)
2: LIN 2 status (OK/Error)
3: LIN 3 status (OK/Error)
4: LIN 4 status (OK/Error)

Správná AR verze:
Part No SW: 1K0 959 433 AR
Component: BCM PQ35 H+ 103 0221
(nebo 0223 pro AR2)

HW musí být také AR!
